Air pre-filters are commonly used in various HVAC (Heating, Ventilation, and Air Conditioning) systems to improve indoor air quality.
They are typically installed as the first line of defense in the filtration process, designed to capture larger particles such as dust, pollen, and pet dander, before they reach more advanced filtration systems, protecting the more delicate and expensive filters downstream.
Air pre-filters extend the lifespan of primary filters and enhance overall air filtration efficiency.
Prefiltration Filter
Applications
- Mainly used in HVAC systems
- Paint booth facilities: traping overspray and large paint particles
- Manufacturing: safeguards equipment and machinery
- Cleanrooms: pharmaceuticals, electronics, and healthcare
- Automotive facilities: protecting sensitive equipment
Features
- Grade: G2, G3, G4
- Synthetic fibers
- Engineered to effectively capture larger particles
- Reliable quality, highly functional air prefilters extend the lifespan of the next filter stage or main filters
- High dust holding capacity for optimum performance
- Maintaining minimal airflow resistance
- Advanced technology cuts down energy cost
- Long service life with proper washing and vacuuming
- Customizable media sizes and thicknesses for different dust-loading applications
| Type | Filter class ISO 16890 (EN 779) |
Weight per unit (g/m2) |
Thickness mm |
Initial pressure drop Pa |
Velocity m/s |
|---|---|---|---|---|---|
| EA 30 | ISO Coarse 65% (G4) | 350 | 30 | 30 | 1 |
| EA 40 | ISO Coarse 65% (G4) | 400 | 40 | 35 | 1 |
| EA 50 | ISO Coarse 70% (G4) | 450 | 50 | 41 | 1 |
| FL 100 | ISO Coarse 40% (G2) | 100 | 6 | 21 | 1.5 |
| FL 150 | ISO Coarse 45% (G2) | 150 | 11 | 27 | 1.5 |
| FL 200 | ISO Coarse 50% (G3) | 200 | 22 | 30 | 1.5 |
| FL 220 | ISO Coarse 65% (G4) | 220 | 24 | 18 | 1 |
